Safe storage of fuel for hydrogen-cars | |||
---|---|---|---|
Until now | Patent | ||
![]() |
< Refuelling > |
![]() | |
![]() |
![]() | ||
- Refuelling at hydrogen filling station only - Storage of hydrogen is in filling station in bottles - Flammable and explosible at disaster |
• Refuelling everywhere: with electricity • Hydrogen gas is developing under charging • NOT flammable and explosible at disaster | ||
![]() |
![]() | ||
![]() |
Storage of hydrogen in the car | ![]() | |
![]() |
![]() | ||
- In hydrogen tank at 200 atm. - Flammable and explosible at disaster |
• In the new type of device without press (patented) • NOT flammable and explosible at disaster | ||
![]() |
![]() | ||
![]() |
Regain of hydrogen from the tank |
![]() | |
![]() |
![]() |
||
- By warming. - Flammable and explosible at disaster |
• By electricity (very low power) • NOT flammable and explosible at disaster | ||
![]() |
![]() | ||
Fuel Cell ®RunningProduct of combustion: H2O - (Zero Emission Vehicle, ZEV) |
